32 Inch PCAP Touch Monitor IP65 Waterproof Anti-vandal for Kiosks
Description of PCAP Touch Monitor
This 32 inch PCAP touch monitor delivers curved design, high durability, accuracy and great touch experience, IP65 front frame waterproof, dust-proof and anti-vandal, which can be used in harsh environment normally. VGA and DVI interfaces are provided for use. In addition, other sizes (7’’-43’’) can be for your option. And with professional R&D department, customized services can be offered to meet customer’s individual needs.
Specification of PCAP Touch Monitor
| Complete Machine |
| Model No. | KOT-0320U-CA5P (P/N:KOT-320P-026) |
| Series | OT |
| Display Type | 16:9 Ratio 32" TFT-LCD |
| Active Area | 698.4 x 392.85(mm) |
| Monitor Dimensions (W*H*D) | 768.4*456*109.6(mm) |
| Suggested Resolution | 1920x1080 @ 60Hz |
| Support Colors | 16.7M |
| Brightness (Typ.) | Pure LCD Panel | 250cd/m2 |
| | With Touch Monitor | 213cd/m2 |
| Response Time (Typ.) | 21ms |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 89°/89°(Typ.)/80°/80°(Min.) |
| | Vertical(up/down) | 89°/89°(Typ.)/80°/80°(Min.) |
| Contrast Ratio (Typ.) | 2100:1 (Min.) /3000:1(Typ.) |
| Video Input | VGADVI |
| Frequency (H/V) | 54.15～84.38KHz / 49～72Hz |
| Power Supply | Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
| Environment | Operating Temp. | 0～50°C |
| | Operating RH | 20%～80% |
| | Storage Temp. | -20～60°C |
| | Storage RH | 10%～90% |
| MTBF | ≥30,000 Hours |
| LED Back Light Life (Typ.) | ≥30,000 Hours |
| Power Consumption | Standby Power: ≤2W / Operating Power: ≤40W |
| Mount Interface | VESA 200mm |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| | Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset |
| Regular Warranty | 1 year |
| Touch Screen |
| Touch Type | 32" Capacitive touch screens |
| Touch input | USB |
| Response Time | ≤14ms |
| Hardness | 6H |
| Light Transmittance | ≥85% |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Active Area | 692.7*392(mm) |
| Thickness | 3.8±0.2(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
PCAP Touch Monitor Mechanical Dimensions
Applications
PCAP Touch Monitor are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
Why choose us?
1. Quality products: All our products have passed strict quality inspection by the quality department before shipment.
2. Competitive pricing: With a strong supply chain, our products’ prices are very competitive.
3. Timely delivery: We have raw materials in stock all year round, the goods can be produced and sent out quickly.
4. Responsive Customer Service: Professional after-sales team at any time to provide services to customers.
FAQ
1. What package do you provide for the PCAP touch monitor?
Our package usually is carton.
2. Do you have stock?
Yes, we have a large quantity of stock for our regular model products.
3. What are the shipping ways?
We will ship the goods according to customer’s requirement. For sample, normally by FedEx, DHL, UPS, TNT. For bulk order, by air or by sea.
4. Do you give any discount for the PCAP touch monitor?
We will do utmost to support you with the competitive price, also good service will be offered.
